Description

• The Elite Series SY48 Thru-Hull produces 22000 fixture lumens.
• Formidable performance with the added security of a thru-hull stem fitting.
• Available in single colour or RGBW Colour Change model with full WIFI DMX compatibility.
• RGBW Colour Change model can be controlled via our dedicated touchpad controller or via a 3rd party device such as i phone, android or tablet, alternatively the lights can be integrated into the yachts existing control system.
• 2 year warranty
• RINA Type approval
• Delrin isolation sleeve must be used on Steel, Aluminium or Carbon composite hulls

Specifications

• Suitable for transom mounting
• Thru-Hull fitting requires 25mm/1″ entry hole
• Fixture Lumens 22,000
• Typical LED life expectancy 50,000 + hours
• Voltage 110-240V
• Over/under voltage,reverse polarity,active thermal rollback protection
• Fixture profile 32mm
• Fixture diameter 140mm
• Fixture Length 208.5mm
• Lens: optical grade 8mm Boroscilicate glass
• 65 degree beam angle
• Body AB2 Bronze throughout
• Weight 2.7kg/5.94lbs
• External Driver
• 2 years warranty
• RINA Type approval
• Delrin Isolation Sleeve kits must be used if fitting lights to Aluminium/Steel or Carbon hulls.
