Description

• Thru Hull interchangeable Flush-mount.
• The Elite Series SY48 IFM  produces 22000 fixture lumens.
• Almost unlimited mounting options thanks to its ultra-low profile bezel.
• Thru Hull mounting offers secure fixing with the additional benefit of a removable LED cartridge that can be serviced inside the hull.
• Available in single colour or RGBW Colour Change model with full WIFI DMX compatibility.
• RGBW Colour Change model can be controlled via our dedicated touchpad controller or via a 3rd party device such as i phone, android or tablet, alternatively the lights can be integrated into the yachts existing control system.
• 2 year warranty
• Delrin isolation sleeve must be used on Steel, Aluminium or Carbon composite hulls
• RINA Type approval

Specifications

• Suitable transom/hull mounting
• Thru-Hull interchangeable requires 101mm/4″ entry hole
• Fixture Lumens 22,000
• Typical LED life expectancy 50,000 + hours
• Voltage 110-240V
• Over/under voltage,reverse polarity,active thermal rollback protection
• Fixture profile 4mm
• Fixture diameter 140mm
• Fixture Length 123.7mm
• Lens: optical grade 8mm Boroscilicate glass
• 65 degree beam angle
• Body AB2 Bronze throughout
• Weight 5.2kg/11.44lbs
• External Driver
• 2 years warranty
• Delrin Isolation Sleeve must be used if fitting lights to Aluminium/Steel or carbon hulls
• RINA Type approval
