Description

Platform Rescue Boat Davit – Reliable Launching System for Offshore Emergency Response

The Platform Rescue Boat Davit from CMEC FJCN is purpose-built for offshore oil rigs, gas platforms, and fixed maritime structures, offering a reliable and rapid launching solution for rescue boats and fast rescue crafts. This system is engineered to operate in challenging offshore conditions, where precision, safety, and durability are critical.

The davit system features a fixed-arm or slewing-arm structure, with a gravity or hydraulic-powered winch, allowing the crew to quickly lower or retrieve the rescue boat with minimal manual effort. Designed for permanent installation on offshore platforms, it provides a compact footprint without compromising load capacity or deployment speed.

With SOLAS and IMO compliance, the Platform Rescue Boat Davit ensures operational readiness during both routine drills and emergency evacuations. Its self-contained control system, robust materials, and corrosion-resistant coatings make it ideal for long-term use in marine environments.

Key Features and Benefits:

• Engineered for offshore platforms – stable performance in harsh sea conditions

• Fast and safe rescue boat deployment – ideal for emergency situations

• Compact structure – suitable for fixed deck installations

• Gravity-assisted or hydraulic winch operation – energy-efficient and reliable

• Corrosion-resistant construction – built to endure saltwater exposure

• Self-contained control system – manual, electric, or hydraulic options

• Low maintenance design – long service life with minimal upkeep

• Complies with SOLAS, LSA Code, and IMO standards

The system includes a davit arm, winch drum, wire rope system, limit switches, and control panel. The boat is stored in a ready-to-launch position, and the davit allows smooth outboard slewing or lowering at the push of a button. Recovery operations are just as efficient, with hydraulic or manual hoisting for secured retrieval.

Technical Specifications:

• Safe Working Load: 15–30 kN (customizable)

• Slewing Type: Fixed or rotating arm (manual or powered)

• Lowering Speed: 0.3–1.0 m/s

• Operation Mode: Manual, hydraulic, or electro-hydraulic

• Material: Marine-grade steel with anti-corrosion treatment

• Surface Finish: Epoxy primer and polyurethane topcoat

• Power Supply: 380V AC or 24V DC (optional backup)

• Ambient Temperature Range: –20°C to +45°C

• Compliance: SOLAS, IMO, LSA Code, MSC.81(70)

• Certifications: CCS, ABS, DNV, BV, LR

CMEC FJCN’s Platform Rescue Boat Davit is delivered fully assembled or modular, with installation instructions, test certificates, and user manuals. Optional features such as remote control, shock absorbers, or automatic release hooks can be added to suit specific operational requirements.

This davit is an essential component of any offshore safety system, offering speed, reliability, and compliance in a durable and easy-to-use package.
