Description
NOMADE is a 24,5 dB gain omnidirectional TV DVB-T2 / TNT and HDTV antenna for boats and mobile vehicles: it’s compact (245mm / 9,7” diameter x 80mm / 3,2” height), light-weight (200g / 7oz) and very easy to be installed also on inclined surfaces thanks to the integrated adjustable mount -15° / +15°. Designed for low wind resistance, with its low noise built-in amplifier, 5m integrated coax cable and 12V power inserter, it’s the best choice to watch TV anytime, anywhere.
Specifications
| ANTENNA DIAMETER | 245mm (9,7”) |
| ANTENNA HEIGHT | 80mm (3,2”) |
| BASE DIAMETER | Integrated mounting plate |
| ANTENNA WEIGHT | 200g (7oz) |
| RADOME MATERIAL | ASA |
| ANGLE OF RECEPTION | 360° |
| POLARIZATION | Horizontal |
| IMPEDANCE | 75 OHMS |
| FREQUENCY RANGE | 170/890 MHz |
| GAIN AVERAGE | 24.5 dB |
| NOISE FACTOR | 1.7 dB |
| POWER CONSUMPTION | 20 mA |
| POWER SUPPLY | 12 Vdc |
| TV SET MAX | 1 |
| TERMINATION | Cable + F connector |
