Description
The HPx-410 PCIe Radar Input Card is a high-performance PCIe radar input card engineered by Cambridge Pixel for advanced radar acquisition. Designed to handle both analogue and digital primary radar video, it supports one or two radars via dual independent input channels. The card leverages a x4 PCI Express interface (also available in x1) and a dedicated FPGA core to deliver very high data throughput, making it ideal for modern, high-resolution, multi-channel radar systems.
Its analogue inputs are sampled at up to 125 MHz with 12-bit A-to-D conversion, capturing detailed radar returns. The captured video can be optionally down-sampled to reduce data volume before being pushed via DMA over the PCIe bus. Onboard processing handles data capture, correlation, and pre-trigger compensation, ensuring accurate and reliable radar data delivery to host systems.
The card supports a wide range of radar signal types, including video, trigger, and azimuth (ACP/ARP or parallel), making it compatible with many radar models—from commercial to specialist military systems. It also includes loss-of-signal detection and configurable I/O for system integration. Compatible with both Windows and Linux, the HPx-410 is fully supported by Cambridge Pixel’s SPx software suite for advanced radar processing, tracking, and display.
Technical Specifications for HPx-410 PCIe Radar Input Card
| Parameter | Specification |
|---|---|
| Form Factor | PCI Express (x1 or x4, half-length, full-height) |
| Sampling Rate | Up to 125 MHz (analogue inputs) |
| A-to-D Resolution | 12-bit |
| Maximum Input Bandwidth | 60 MHz |
| Pulse Repetition Frequency (PRF) | 0 to 16 kHz |
| Samples per Return (max) | Up to 64,000 |
| Returns per Scan | Up to 16,000 |
| Azimuth Inputs | 2 × ACP/ARP (RS422 or single-ended) + 1 × parallel azimuth |
| Trigger Inputs | 2 × (RS422, single-ended, opto-isolated) |
| Video Termination Options | 50 Ω, 75 Ω, or high impedance |
| Data Transfer Rate (PCIe) | x4: up to 500 MB/s (peak), sustained ~250MB/s x1: up to 250 MB/s (peak), ~150MB/s sustained |
| General Purpose I/O | 3 lines (configurable as input or output) |
| Built-in Test | Test pattern generator onboard |
| Software Support | Board Support Library (C/C++), SPx Development Library, Radar View, SPx Server |
| Supported Radar Types | Wide variety: commercial & military (e.g., Furuno, JRC, Raytheon, Terma, etc.) |
| Operating Temperature | 0 °C to +55 °C |
| Other Features | Signal-loss detection, programmable pre-trigger delay, video mixing (analogue + digital) |
Features
-
Very high data throughput via PCIe x4 interface
-
Dual-stream capability: supports two radars simultaneously or dual redundancy
-
125 MHz sampling for fine radar return resolution
-
12-bit ADC for high-fidelity signal capture
-
Flexible signal support: analogue video, digital, trigger, azimuth (ACP/ARP or parallel)
-
Loss-of-signal detection with software alerts
-
Configurable pre-trigger compensation for timing accuracy
-
Onboard FPGA for real-time processing and correlation
-
Built-in pattern generator for testing and diagnostics
-
3 general-purpose I/O lines for system integration
-
Compatible with Cambridge Pixel’s SPx software suite (for processing, tracking, display)
-
Support for Windows and Linux via board support library
