Description
GN150 series multi-system shipborne radionavigation receivers are the first products in this category to be certified by CCS in China, it supports multi-mode high precision positioning, multi-language display to satisfy the requirements of different user groups.
• Passed the EU CE certification, China Classification Society CCS type approval.
• 15 inch color LCD with 1024 x 768 resolution.
• Super cortex-A17 processor with high-capacity storage, born to be strong, never settle.
• Built-in high-precision BDS/GPS multi-mode positioning module, support RTCM2.3 DGNSS input.
• Self-developed SOG&COG filtering algorithm which can intelligently match ship types to achieve stable SOG&COG output.
• Connect to mobile network to upgrade software online.
• Install in intelligent voice to broadcast operation content, alarm content, etc.
• Classic& Utility dual operating system, you can switch freely.
• Power failure will immediately alarm to ensure the device work well.
The device includes features tailored for ship-board navigation environments: a self-developed SOG (Speed Over Ground) & COG (Course Over Ground) filtering algorithm that adapts to vessel type, intelligent voice broadcast of operational and alarm messages, dual OS (Classic & Utility) allowing user choice of interface style, and a power‐failure alarm to immediately flag power issues.
In addition to positioning and display, the GN150 (15″) supports multi-language interface, online software upgrade via mobile network connectivity, compatibility with maritime chart data, and is built for installation in ship bridge environments with attention to reliability and marine certification.
Technical Specifications
| Display Unit | GN150(15″) | |
| Display Type | Color TFT LCD | |
| Size | 15 inch | |
| Resolution | 1024*768 | |
| Brightness | 450cd/㎡ | |
| Language | English, Simplified Chinese, Traditional Chinese, Vietnamese, Bahasa Malaysia, Turkish, Thai, Greek, Indonesian, Japanese, Korean, Spanish, Burmese, Persian | |
| Display Modes | Standard Chart View, Pure Chart View, Simple Chart View, AIS Data, Sailing Data, GNSS, 3D Navigation, Compass | |
| Memory Capacity | 50,000 waypoints, 50,000 markers, 500 routes, one route can indicate 200 waypoints , 1000 tracks, 1600000 track points | |
| Interface | 3 Ports NMEA0183 Output , 3 Ports NMEA0183 Input (Baud rate can be set indenpently) | |
| WIFI | 802.11 b/g/n | |
| Power Supply | DC12V~36V | |
| Power Consumption | 12W or less (24V DC) | |
| Enviromental | ||
| Working Temperature | -15℃~+55℃ | |
| Storage Temperature | -20℃~+60℃ | |
| Waterproof | IP65 | |
