Ballade
The Supergain Ballade (Glomex SGT5000) is a compact, omnidirectional digital TV antenna for marine and RV use, offering 360° signal reception with a built-in 23.5 dB amplifier.
Description
BALLADE is a 23,5 dB gain omnidirectional TV DVB-T2 / TNT and HDTV compatible antenna for boats and mobile vehicles: it’s super-compact (70 mm / 2,8” diameter x 165mm / 6,5” height), extra light-weight (110g / 4oz) and easy to be installed thanks to the integrated mount. Powered by low noise built-in amplifier, supplied with 12V power inserter and integrated 5m coax cable, it’s the best value for money.
Specifications
| ANTENNA DIAMETER | 70mm (2,8”) |
| ANTENNA HEIGHT | 165mm (6,5”) |
| BASE DIAMETER | Integrated mounting plate |
| ANTENNA WEIGHT | 110g (4oz) |
| RADOME MATERIAL | ASA |
| ANGLE OF RECEPTION | 360° |
| POLARIZATION | Horizontal |
| IMPEDANCE | 75 OHMS |
| FREQUENCY RANGE | 170/890 MHz |
| GAIN AVERAGE | 23.5 dB |
| NOISE FACTOR | 1.7 dB |
| POWER CONSUMPTION | 20 mA |
| POWER SUPPLY | 12 Vdc |
| TV SET MAX | 1 |
| TERMINATION | Cable + F connector |
Additional information
| Brand | Glomex |
|---|
