Description

1×127 to 1×631 Single Twist Wire Rope refers to monostrands (single-strand wire ropes) composed of 127 to 631 individual fine wires, twisted concentrically into a single helical unit. Each construction follows a multi-layer spiral configuration (e.g., 1 + 6 + 12 + 18 + ...), with increasing outer layers to reach the designated wire count. As the strand count increases, these ropes offer exceptionally smooth surface finishes, higher flexibility, increased fatigue resistance, and minimal elongation, making them ideal for high-precision, low-tolerance and aesthetic-critical structural applications.

Feature of 1×127-1×631 Single Twist Wire Rope

Exceptional Strength: The 1×127 to 1×631 construction provides outstanding load-bearing capacity, making it ideal for high-strength applications in heavy-duty lifting, suspension, and structural support. High Load Capacity: Designed to carry heavy loads safely, providing efficiency in lifting and rigging tasks. Durable Construction: Resistant to abrasion, corrosion, and wear, ideal for use in tough and outdoor conditions. Corrosion-Resistant: Coated with anti-corrosion materials, these ropes retain their strength and appearance in marine, humid, or exposed environments. Flexible & Maneuverable: Despite their strength, the ropes maintain excellent flexibility, making them easy to handle for all types of lifting and rigging. Custom Sizes: Available in various diameters, lengths, and configurations to meet specific needs and applications.

Technical Specification

Rope Construction: 1 strand of wire twisted into 127 to 631 individual wires Rope Nominal Diameter: Customized Length: Customized Surface: Galvanized/Smooth Nominal Tensile Strength: 1570 N/mm²~1770N/mm² Standards: Meets national and international standards, including GB/T20118, EN, GOST, and API Place of Origin: Hebei, China Brand Name: J&L Application: Structural parts for stadiums, suspension cables, components for tension structures, cableways, etc.
